Perle IOLAN SCG50 S Console Server

IOLAN SCG50 S Console Server: 48 x software selectable RS232/422/485 RJ45 interfaces, 2 x USB Ports, Front Panel Display and Keyboard, 2 x auto-sensing 10/100/1000 Ethernet Combo Ports (RJ45 or SFP), Micro SD Card Slot, Micro USB and RS232 RJ45 Console Admin Ports, IPv4/IPv6 routing (RIP, OSPF, BGP), ZTP, REST / Python, Cloud-hosting, advanced data encryption, user authentication and event management security features included, COM port redirector, 15kv ESD, Dual AC Power, adapter cord included.

The Perle IOLAN SCG S Console Servers incorporate EIA-232, EIA-422, and EIA-485 signals on a single RJ45 interface, enabling secure serial data transmission over IP networks. The ability to individually configure each interface type using software commands enables organizations to access and support a variety of serial-based devices in their network. The modular design of the IOAN SCG allows the user to swap, upgrade and scale to anymix-and-matchcombination of 16-port USB 3.0, RS232 RJ45, or software-selectable RS232/422/485 RJ45 interface module cards.

With functionality that includes full routing capabilities with support for RIP, OSPF, and BGP protocols, Zero Touch Provisioning (ZTP), two-factor authentication (2FA), integrated firewall, advanced failover to multiple networks, advanced network security features, recognized authentication schemes, and leading-edge data encryption tools, IT administrators can feel confident that network data transmissions, and all access to the console admin ports on IT equipment, is secure.

Perle IOLAN SCG50 S Console Server

IOLAN SCG50 S Console Server: 48 x software selectable RS232/422/485 RJ45 interfaces, 2 x USB Ports, Front Panel Display and Keyboard, 2 x auto-sensing 10/100/1000 Ethernet Combo Ports (RJ45 or SFP), Micro SD Card Slot, Micro USB and RS232 RJ45 Console Admin Ports, IPv4/IPv6 routing (RIP, OSPF, BGP), ZTP, REST / Python, Cloud-hosting, advanced data encryption, user authentication and event management security features included, COM port redirector, 15kv ESD, Dual AC Power, adapter cord included.

The Perle IOLAN SCG S Console Servers incorporate EIA-232, EIA-422, and EIA-485 signals on a single RJ45 interface, enabling secure serial data transmission over IP networks. The ability to individually configure each interface type using software commands enables organizations to access and support a variety of serial-based devices in their network. The modular design of the IOAN SCG allows the user to swap, upgrade and scale to anymix-and-matchcombination of 16-port USB 3.0, RS232 RJ45, or software-selectable RS232/422/485 RJ45 interface module cards.

With functionality that includes full routing capabilities with support for RIP, OSPF, and BGP protocols, Zero Touch Provisioning (ZTP), two-factor authentication (2FA), integrated firewall, advanced failover to multiple networks, advanced network security features, recognized authentication schemes, and leading-edge data encryption tools, IT administrators can feel confident that network data transmissions, and all access to the console admin ports on IT equipment, is secure.

Perle by Perle

Perle IOLAN SCG50 S Console Server - 1000 MB - Twisted Pair, Optical Fiber - 2 Total Expansion Slot(s) - 2 x Network (RJ-45) - 3 x USB - 48 x Serial Port - 10/100/1000Base-T, 1000Base-X - Gigabit Ethernet - Management Port - Rack-mountable

Regular price
$7,719.13
Sale price
$7,719.13
Regular price
$10,238.70
Mfg Part No: 04035284
SKU: 1072132118
Out of stock

This product is unavailable!
